Series RG-50A
Price scales
| Quantity | Discount | Unit price |
| 1-9 | 0% off | $9.99 |
| 10-99 | 15% off | $8.49 |
| 100+ | 25% off | $7.49 |
Product description
RG-50
Specifications
Series RG50A-3415Kn : 630 kgf.cm75 kgf.cm341550 mm37.7 mm- Series RG50A-1856Kn : 630 kgf.cm75 kgf.cm185650 mm37.7 mm
- Series RG50A-853Kn : 530 kgf.cm75 kgf.cm85350 mm33.9 mm
- Series RG50A-464Kn : 530 kgf.cm75 kgf.cm46450 mm33.9 mm
- Series RG50A-213Kn : 430 kgf.cm75 kgf.cm21350 mm30.2 mm
- Series RG50A-116Kn : 430 kgf.cm75 kgf.cm11650 mm30.2 mm
- Series RG50A-53Kn : 310 kgf.cm30 kgf.cm5350 mm26.4 mm
- Series RG50A-29Kn : 310 kgf.cm30 kgf.cm2950 mm26.4 mm
- Series RG50A-13.3Kn : 210 kgf.cm30 kgf.cm13.350 mm26.4 mm
- Series RG50A-7.2Kn : 210 kgf.cm30 kgf.cm7.250 mm26.4 mm
| Gearbox Characteristic Data | |
| Model | RG50A - 50 mm Spur Gearbox |
| Gearbox housing material | Zinc Alloy （Die casting） |
| Gear material | Powder Metallurgy (Fe) / Plastics / Steel |
| Gear design | Helical Gear / Spur Gear |
| Bearing at output shaft | Sleeve Bearing |
| Lubricant in gearbox | FUMIO |
| Shaft axial load | ≤ 1.0 kgf |
| Radial load | ≤ 1.0 kgf |
| Axial play | ≤ 0.35 mm |
| Radial play | ≤ 0.05 mm |
| Backlash at no-load | ≤ 2° |
| Gear module | 0.5 M / 0.6 M / 0.8 M |
| Gearbox Value | |
| Gear ratio | 3415 |
| Number of gear stage | 6 |
| Gearbox length | 37.3 mm |
| Max continuous torque | 30 kgf.cm |
| Instantaneous break torque | 75 kgf.cm |
| Gearbox efficiency | 53 % |
| Gearbox mass | 126 g |
| Output shaft diameter | 8 mm |
| Pinion hole diameter | φ 2.5 / φ 3.1 |
| Operating temperature range | -20 ... 65 °C |
| Electrical characteristics | |
| Terminal resistance | |
| Terminal inductance | |
| Torque constant | |
| Speed constant | |
| Back-EMF constant | |
| Rotor inductance | |
| Rotor inertia | |
| Mechanical characteristics | |
| Weight | 103 g |
| Noise Level @ 30cm | 53 dB |
| Noise Level @ 50cm | 48 dB |
| Operating temperature range | -40℃-100℃ |
| Working Lifespan | 3000 hours |
| Gearbox Characteristic Data | |
| Model | RG50A - 50 mm Spur Gearbox |
| Gearbox housing material | Zinc Alloy （Die casting） |
| Gear material | Powder Metallurgy (Fe) / Plastics / Steel |
| Gear design | Helical Gear / Spur Gear |
| Bearing at output shaft | Sleeve Bearing |
| Lubricant in gearbox | FUMIO |
| Shaft axial load | ≤ 1.0 kgf |
| Radial load | ≤ 1.0 kgf |
| Axial play | ≤ 0.35 mm |
| Radial play | ≤ 0.05 mm |
| Backlash at no-load | ≤ 2° |
| Gear module | 0.5 M / 0.6 M / 0.8 M |
| Gearbox Value | |
| Gear ratio | 1856 |
| Number of gear stage | 6 |
| Gearbox length | 37.3 mm |
| Max continuous torque | 30 kgf.cm |
| Instantaneous break torque | 75 kgf.cm |
| Gearbox efficiency | 53 % |
| Gearbox mass | 126 g |
| Output shaft diameter | 8 mm |
| Pinion hole diameter | φ 2.5 / φ 3.1 |
| Operating temperature range | -20 ... 65 °C |
| Electrical characteristics | |
| Terminal resistance | |
| Terminal inductance | |
| Torque constant | |
| Speed constant | |
| Back-EMF constant | |
| Rotor inductance | |
| Rotor inertia | |
| Mechanical characteristics | |
| Weight | 103 g |
| Noise Level @ 30cm | 53 dB |
| Noise Level @ 50cm | 48 dB |
| Operating temperature range | -40℃-100℃ |
| Working Lifespan | 3000 hours |
| Gearbox Characteristic Data | |
| Model | RG50A - 50 mm Spur Gearbox |
| Gearbox housing material | Zinc Alloy （Die casting） |
| Gear material | Powder Metallurgy (Fe) / Plastics / Steel |
| Gear design | Helical Gear / Spur Gear |
| Bearing at output shaft | Sleeve Bearing |
| Lubricant in gearbox | FUMIO |
| Shaft axial load | ≤ 1.0 kgf |
| Radial load | ≤ 1.0 kgf |
| Axial play | ≤ 0.35 mm |
| Radial play | ≤ 0.05 mm |
| Backlash at no-load | ≤ 2° |
| Gear module | 0.5 M / 0.6 M / 0.8 M |
| Gearbox Value | |
| Gear ratio | 853 |
| Number of gear stage | 5 |
| Gearbox length | 33.9 mm |
| Max continuous torque | 30 kgf.cm |
| Instantaneous break torque | 75 kgf.cm |
| Gearbox efficiency | 59 % |
| Gearbox mass | 126 g |
| Output shaft diameter | 8 mm |
| Pinion hole diameter | φ 2.5 / φ 3.1 |
| Operating temperature range | -20 ... 65 °C |
| Electrical characteristics | |
| Terminal resistance | |
| Terminal inductance | |
| Torque constant | |
| Speed constant | |
| Back-EMF constant | |
| Rotor inductance | |
| Rotor inertia | |
| Mechanical characteristics | |
| Weight | 103 g |
| Noise Level @ 30cm | 53 dB |
| Noise Level @ 50cm | 48 dB |
| Operating temperature range | -40℃-100℃ |
| Working Lifespan | 3000 hours |
| Gearbox Characteristic Data | |
| Model | RG50A - 50 mm Spur Gearbox |
| Gearbox housing material | Zinc Alloy （Die casting） |
| Gear material | Powder Metallurgy (Fe) / Plastics / Steel |
| Gear design | Helical Gear / Spur Gear |
| Bearing at output shaft | Sleeve Bearing |
| Lubricant in gearbox | FUMIO |
| Shaft axial load | ≤ 1.0 kgf |
| Radial load | ≤ 1.0 kgf |
| Axial play | ≤ 0.35 mm |
| Radial play | ≤ 0.05 mm |
| Backlash at no-load | ≤ 2° |
| Gear module | 0.5 M / 0.6 M / 0.8 M |
| Gearbox Value | |
| Gear ratio | 464 |
| Number of gear stage | 5 |
| Gearbox length | 33.9 mm |
| Max continuous torque | 30 kgf.cm |
| Instantaneous break torque | 75 kgf.cm |
| Gearbox efficiency | 59 % |
| Gearbox mass | 126 g |
| Output shaft diameter | 8 mm |
| Pinion hole diameter | φ 2.5 / φ 3.1 |
| Operating temperature range | -20 ... 65 °C |
| Electrical characteristics | |
| Terminal resistance | |
| Terminal inductance | |
| Torque constant | |
| Speed constant | |
| Back-EMF constant | |
| Rotor inductance | |
| Rotor inertia | |
| Mechanical characteristics | |
| Weight | 103 g |
| Noise Level @ 30cm | 53 dB |
| Noise Level @ 50cm | 48 dB |
| Operating temperature range | -40℃-100℃ |
| Working Lifespan | 3000 hours |
| Gearbox Characteristic Data | |
| Model | RG50A - 50 mm Spur Gearbox |
| Gearbox housing material | Zinc Alloy （Die casting） |
| Gear material | Powder Metallurgy (Fe) / Plastics / Steel |
| Gear design | Helical Gear / Spur Gear |
| Bearing at output shaft | Sleeve Bearing |
| Lubricant in gearbox | FUMIO |
| Shaft axial load | ≤ 1.0 kgf |
| Radial load | ≤ 1.0 kgf |
| Axial play | ≤ 0.35 mm |
| Radial play | ≤ 0.05 mm |
| Backlash at no-load | ≤ 2° |
| Gear module | 0.5 M / 0.6 M / 0.8 M |
| Gearbox Value | |
| Gear ratio | 213 |
| Number of gear stage | 4 |
| Gearbox length | 30.2 mm |
| Max continuous torque | 30 kgf.cm |
| Instantaneous break torque | 75 kgf.cm |
| Gearbox efficiency | 65 % |
| Gearbox mass | 126 g |
| Output shaft diameter | 8 mm |
| Pinion hole diameter | φ 2.5 / φ 3.1 |
| Operating temperature range | -20 ... 65 °C |
| Electrical characteristics | |
| Terminal resistance | |
| Terminal inductance | |
| Torque constant | |
| Speed constant | |
| Back-EMF constant | |
| Rotor inductance | |
| Rotor inertia | |
| Mechanical characteristics | |
| Weight | 103 g |
| Noise Level @ 30cm | 53 dB |
| Noise Level @ 50cm | 48 dB |
| Operating temperature range | -40℃-100℃ |
| Working Lifespan | 3000 hours |
| Gearbox Characteristic Data | |
| Model | RG50A - 50 mm Spur Gearbox |
| Gearbox housing material | Zinc Alloy （Die casting） |
| Gear material | Powder Metallurgy (Fe) / Plastics / Steel |
| Gear design | Helical Gear / Spur Gear |
| Bearing at output shaft | Sleeve Bearing |
| Lubricant in gearbox | FUMIO |
| Shaft axial load | ≤ 1.0 kgf |
| Radial load | ≤ 1.0 kgf |
| Axial play | ≤ 0.35 mm |
| Radial play | ≤ 0.05 mm |
| Backlash at no-load | ≤ 2° |
| Gear module | 0.5 M / 0.6 M / 0.8 M |
| Gearbox Value | |
| Gear ratio | 116 |
| Number of gear stage | 4 |
| Gearbox length | 30.2 mm |
| Max continuous torque | 30 kgf.cm |
| Instantaneous break torque | 75 kgf.cm |
| Gearbox efficiency | 65 % |
| Gearbox mass | 126 g |
| Output shaft diameter | 8 mm |
| Pinion hole diameter | φ 2.5 / φ 3.1 |
| Operating temperature range | -20 ... 65 °C |
| Electrical characteristics | |
| Terminal resistance | |
| Terminal inductance | |
| Torque constant | |
| Speed constant | |
| Back-EMF constant | |
| Rotor inductance | |
| Rotor inertia | |
| Mechanical characteristics | |
| Weight | 103 g |
| Noise Level @ 30cm | 53 dB |
| Noise Level @ 50cm | 48 dB |
| Operating temperature range | -40℃-100℃ |
| Working Lifespan | 3000 hours |
| Gearbox Characteristic Data | |
| Model | RG50A - 50 mm Spur Gearbox |
| Gearbox housing material | Zinc Alloy （Die casting） |
| Gear material | Powder Metallurgy (Fe) / Plastics / Steel |
| Gear design | Helical Gear / Spur Gear |
| Bearing at output shaft | Sleeve Bearing |
| Lubricant in gearbox | FUMIO |
| Shaft axial load | ≤ 1.0 kgf |
| Radial load | ≤ 1.0 kgf |
| Axial play | ≤ 0.35 mm |
| Radial play | ≤ 0.05 mm |
| Backlash at no-load | ≤ 2° |
| Gear module | 0.5 M / 0.6 M / 0.8 M |
| Gearbox Value | |
| Gear ratio | 53 |
| Number of gear stage | 3 |
| Gearbox length | 26.4 mm |
| Max continuous torque | 10 kgf.cm |
| Instantaneous break torque | 30 kgf.cm |
| Gearbox efficiency | 73 % |
| Gearbox mass | 126 g |
| Output shaft diameter | 8 mm |
| Pinion hole diameter | φ 2.5 / φ 3.1 |
| Operating temperature range | -20 ... 65 °C |
| Electrical characteristics | |
| Terminal resistance | |
| Terminal inductance | |
| Torque constant | |
| Speed constant | |
| Back-EMF constant | |
| Rotor inductance | |
| Rotor inertia | |
| Mechanical characteristics | |
| Weight | 103 g |
| Noise Level @ 30cm | 53 dB |
| Noise Level @ 50cm | 48 dB |
| Operating temperature range | -40℃-100℃ |
| Working Lifespan | 3000 hours |
| Gearbox Characteristic Data | |
| Model | RG50A - 50 mm Spur Gearbox |
| Gearbox housing material | Zinc Alloy （Die casting） |
| Gear material | Powder Metallurgy (Fe) / Plastics / Steel |
| Gear design | Helical Gear / Spur Gear |
| Bearing at output shaft | Sleeve Bearing |
| Lubricant in gearbox | FUMIO |
| Shaft axial load | ≤ 1.0 kgf |
| Radial load | ≤ 1.0 kgf |
| Axial play | ≤ 0.35 mm |
| Radial play | ≤ 0.05 mm |
| Backlash at no-load | ≤ 2° |
| Gear module | 0.5 M / 0.6 M / 0.8 M |
| Gearbox Value | |
| Gear ratio | 29 |
| Number of gear stage | 3 |
| Gearbox length | 26.4 mm |
| Max continuous torque | 10 kgf.cm |
| Instantaneous break torque | 30 kgf.cm |
| Gearbox efficiency | 73 % |
| Gearbox mass | 126 g |
| Output shaft diameter | 8 mm |
| Pinion hole diameter | φ 2.5 / φ 3.1 |
| Operating temperature range | -20 ... 65 °C |
| Electrical characteristics | |
| Terminal resistance | |
| Terminal inductance | |
| Torque constant | |
| Speed constant | |
| Back-EMF constant | |
| Rotor inductance | |
| Rotor inertia | |
| Mechanical characteristics | |
| Weight | 103 g |
| Noise Level @ 30cm | 53 dB |
| Noise Level @ 50cm | 48 dB |
| Operating temperature range | -40℃-100℃ |
| Working Lifespan | 3000 hours |
| Gearbox Characteristic Data | |
| Model | RG50A - 50 mm Spur Gearbox |
| Gearbox housing material | Zinc Alloy （Die casting） |
| Gear material | Powder Metallurgy (Fe) / Plastics / Steel |
| Gear design | Helical Gear / Spur Gear |
| Bearing at output shaft | Sleeve Bearing |
| Lubricant in gearbox | FUMIO |
| Shaft axial load | ≤ 1.0 kgf |
| Radial load | ≤ 1.0 kgf |
| Axial play | ≤ 0.35 mm |
| Radial play | ≤ 0.05 mm |
| Backlash at no-load | ≤ 2° |
| Gear module | 0.5 M / 0.6 M / 0.8 M |
| Gearbox Value | |
| Gear ratio | 13.3 |
| Number of gear stage | 2 |
| Gearbox length | 26.4 mm |
| Max continuous torque | 10 kgf.cm |
| Instantaneous break torque | 30 kgf.cm |
| Gearbox efficiency | 81 % |
| Gearbox mass | 126 g |
| Output shaft diameter | 8 mm |
| Pinion hole diameter | φ 2.5 / φ 3.1 |
| Operating temperature range | -20 ... 65 °C |
| Electrical characteristics | |
| Terminal resistance | |
| Terminal inductance | |
| Torque constant | |
| Speed constant | |
| Back-EMF constant | |
| Rotor inductance | |
| Rotor inertia | |
| Mechanical characteristics | |
| Weight | 103 g |
| Noise Level @ 30cm | 53 dB |
| Noise Level @ 50cm | 48 dB |
| Operating temperature range | -40℃-100℃ |
| Working Lifespan | 3000 hours |
| Gearbox Characteristic Data | |
| Model | RG50A - 50 mm Spur Gearbox |
| Gearbox housing material | Zinc Alloy （Die casting） |
| Gear material | Powder Metallurgy (Fe) / Plastics / Steel |
| Gear design | Helical Gear / Spur Gear |
| Bearing at output shaft | Sleeve Bearing |
| Lubricant in gearbox | FUMIO |
| Shaft axial load | ≤ 1.0 kgf |
| Radial load | ≤ 1.0 kgf |
| Axial play | ≤ 0.35 mm |
| Radial play | ≤ 0.05 mm |
| Backlash at no-load | ≤ 2° |
| Gear module | 0.5 M / 0.6 M / 0.8 M |
| Gearbox Value | |
| Gear ratio | 7.2 |
| Number of gear stage | 2 |
| Gearbox length | 26.4 mm |
| Max continuous torque | 10 kgf.cm |
| Instantaneous break torque | 30 kgf.cm |
| Gearbox efficiency | 81 % |
| Gearbox mass | 126 g |
| Output shaft diameter | 8 mm |
| Pinion hole diameter | φ 2.5 / φ 3.1 |
| Operating temperature range | -20 ... 65 °C |
| Electrical characteristics | |
| Terminal resistance | |
| Terminal inductance | |
| Torque constant | |
| Speed constant | |
| Back-EMF constant | |
| Rotor inductance | |
| Rotor inertia | |
| Mechanical characteristics | |
| Weight | 103 g |
| Noise Level @ 30cm | 53 dB |
| Noise Level @ 50cm | 48 dB |
| Operating temperature range | -40℃-100℃ |
| Working Lifespan | 3000 hours |
Technical illustrations
Characteristic curves
Your Choice
Selected Variant
RG50A-3415K
Key Features
| Gear stage: | n : 6 |
| Continuous input torque: | 30 kgf.cm |
| Gear breaking torque: | 75 kgf.cm |
| Gear ratio: | 3415 |
| Diameter : | 50 mm |
| Length: | 37.7 mm |
Selected Variant
RG50A-1856K
Key Features
| Gear stage: | n : 6 |
| Continuous input torque: | 30 kgf.cm |
| Gear breaking torque: | 75 kgf.cm |
| Gear ratio: | 1856 |
| Diameter : | 50 mm |
| Length: | 37.7 mm |
Selected Variant
RG50A-853K
Key Features
| Gear stage: | n : 5 |
| Continuous input torque: | 30 kgf.cm |
| Gear breaking torque: | 75 kgf.cm |
| Gear ratio: | 853 |
| Diameter : | 50 mm |
| Length: | 33.9 mm |
Selected Variant
RG50A-464K
Key Features
| Gear stage: | n : 5 |
| Continuous input torque: | 30 kgf.cm |
| Gear breaking torque: | 75 kgf.cm |
| Gear ratio: | 464 |
| Diameter : | 50 mm |
| Length: | 33.9 mm |
Selected Variant
RG50A-213K
Key Features
| Gear stage: | n : 4 |
| Continuous input torque: | 30 kgf.cm |
| Gear breaking torque: | 75 kgf.cm |
| Gear ratio: | 213 |
| Diameter : | 50 mm |
| Length: | 30.2 mm |
Selected Variant
RG50A-116K
Key Features
| Gear stage: | n : 4 |
| Continuous input torque: | 30 kgf.cm |
| Gear breaking torque: | 75 kgf.cm |
| Gear ratio: | 116 |
| Diameter : | 50 mm |
| Length: | 30.2 mm |
Selected Variant
RG50A-53K
Key Features
| Gear stage: | n : 3 |
| Continuous input torque: | 10 kgf.cm |
| Gear breaking torque: | 30 kgf.cm |
| Gear ratio: | 53 |
| Diameter : | 50 mm |
| Length: | 26.4 mm |
Selected Variant
RG50A-29K
Key Features
| Gear stage: | n : 3 |
| Continuous input torque: | 10 kgf.cm |
| Gear breaking torque: | 30 kgf.cm |
| Gear ratio: | 29 |
| Diameter : | 50 mm |
| Length: | 26.4 mm |
Selected Variant
RG50A-13.3K
Key Features
| Gear stage: | n : 2 |
| Continuous input torque: | 10 kgf.cm |
| Gear breaking torque: | 30 kgf.cm |
| Gear ratio: | 13.3 |
| Diameter : | 50 mm |
| Length: | 26.4 mm |
Selected Variant
RG50A-7.2K
Key Features
| Gear stage: | n : 2 |
| Continuous input torque: | 10 kgf.cm |
| Gear breaking torque: | 30 kgf.cm |
| Gear ratio: | 7.2 |
| Diameter : | 50 mm |
| Length: | 26.4 mm |
