Series PG56
Price scales
| Quantity | Discount | Unit price |
| 1-9 | 0% off | $34.9 |
| 10-99 | 15% off | $29.9 |
| 100+ | 25% off | $26.9 |
Product description
PG-56
Specifications
Series PG56-1896Kn : 5400 kgf.cm1200 kgf.cm189656 mm99.2 mm- Series PG56-1356Kn : 5400 kgf.cm1200 kgf.cm135656 mm99.2 mm
- Series PG56-970Kn : 5400 kgf.cm1200 kgf.cm97056 mm99.2 mm
- Series PG56-716Kn : 4400 kgf.cm1200 kgf.cm71656 mm83.2 mm
- Series PG56-512Kn : 4400 kgf.cm1200 kgf.cm51256 mm83.2 mm
- Series PG56-366Kn : 4400 kgf.cm1200 kgf.cm36656 mm83.2 mm
- Series PG56-262Kn : 4400 kgf.cm1200 kgf.cm26256 mm83.2 mm
- Series PG56-138Kn : 3400 kgf.cm1200 kgf.cm13856 mm68.9 mm
- Series PG56-99Kn : 3400 kgf.cm1200 kgf.cm9956 mm68.9 mm
- Series PG56-71Kn : 3400 kgf.cm1200 kgf.cm7156 mm68.9 mm
- Series PG56-27Kn : 2100 kgf.cm300 kgf.cm2756 mm50.4 mm
- Series PG56-19Kn : 2100 kgf.cm300 kgf.cm1956 mm50.4 mm
- Series PG56-5.1Kn : 1100 kgf.cm300 kgf.cm5.156 mm37.5 mm
- Series PG56-3.7Kn : 1100 kgf.cm300 kgf.cm3.756 mm37.5 mm
| Gearbox Characteristic Data | |
| Model | PG56 56 mm Planetary Gearbox |
| Gearbox housing material | Powder Metallurgy (Fe) |
| Gear material | Powder Metallurgy (Fe) / Plastics |
| Gear design | Helical Gear |
| Bearing at output shaft | Ball Bearing |
| Lubricant in gearbox | Graphene oil |
| Axial play | ≤ 0.2mm |
| Radial play | ≤ 0.1mm |
| Backlash at no-load | ≤ 1.5° |
| Gear module | 1 M |
| Gearbox Value | |
| Gear ratio | 1896 |
| Number of gear stage | 5 |
| Gearbox length | 99.2 mm |
| Max continuous torque | 400 kgf.cm |
| Instantaneous break torque | 1200 kgf.cm |
| Gearbox efficiency | 50 % |
| Gearbox mass | 1012.3 g |
| Output shaft diameter | 12 mm |
| Pinion hole diameter | φ 5.97 / φ 7.96 |
| Operating temperature range | -30 ... 65 °C |
| Electrical characteristics | |
| Terminal resistance | |
| Terminal inductance | |
| Torque constant | |
| Speed constant | |
| Back-EMF constant | |
| Rotor inductance | |
| Rotor inertia | |
| Mechanical characteristics | |
| Weight | 349 g |
| Noise Level @ 30cm | 53 dB |
| Noise Level @ 50cm | 48 dB |
| Operating temperature range | -40℃-100℃ |
| Working Lifespan | 3000 hours |
| Gearbox Characteristic Data | |
| Model | PG56 56 mm Planetary Gearbox |
| Gearbox housing material | Powder Metallurgy (Fe) |
| Gear material | Powder Metallurgy (Fe) / Plastics |
| Gear design | Helical Gear |
| Bearing at output shaft | Ball Bearing |
| Lubricant in gearbox | Graphene oil |
| Axial play | ≤ 0.2mm |
| Radial play | ≤ 0.1mm |
| Backlash at no-load | ≤ 1.5° |
| Gear module | 1 M |
| Gearbox Value | |
| Gear ratio | 1356 |
| Number of gear stage | 5 |
| Gearbox length | 99.2 mm |
| Max continuous torque | 400 kgf.cm |
| Instantaneous break torque | 1200 kgf.cm |
| Gearbox efficiency | 50 % |
| Gearbox mass | 1012.3 g |
| Output shaft diameter | 12 mm |
| Pinion hole diameter | φ 5.97 / φ 7.96 |
| Operating temperature range | -30 ... 65 °C |
| Electrical characteristics | |
| Terminal resistance | |
| Terminal inductance | |
| Torque constant | |
| Speed constant | |
| Back-EMF constant | |
| Rotor inductance | |
| Rotor inertia | |
| Mechanical characteristics | |
| Weight | 349 g |
| Noise Level @ 30cm | 53 dB |
| Noise Level @ 50cm | 48 dB |
| Operating temperature range | -40℃-100℃ |
| Working Lifespan | 3000 hours |
| Gearbox Characteristic Data | |
| Model | PG56 56 mm Planetary Gearbox |
| Gearbox housing material | Powder Metallurgy (Fe) |
| Gear material | Powder Metallurgy (Fe) / Plastics |
| Gear design | Helical Gear |
| Bearing at output shaft | Ball Bearing |
| Lubricant in gearbox | Graphene oil |
| Axial play | ≤ 0.2mm |
| Radial play | ≤ 0.1mm |
| Backlash at no-load | ≤ 1.5° |
| Gear module | 1 M |
| Gearbox Value | |
| Gear ratio | 970 |
| Number of gear stage | 5 |
| Gearbox length | 99.2 mm |
| Max continuous torque | 400 kgf.cm |
| Instantaneous break torque | 1200 kgf.cm |
| Gearbox efficiency | 50 % |
| Gearbox mass | 1012.3 g |
| Output shaft diameter | 12 mm |
| Pinion hole diameter | φ 5.97 / φ 7.96 |
| Operating temperature range | -30 ... 65 °C |
| Electrical characteristics | |
| Terminal resistance | |
| Terminal inductance | |
| Torque constant | |
| Speed constant | |
| Back-EMF constant | |
| Rotor inductance | |
| Rotor inertia | |
| Mechanical characteristics | |
| Weight | 349 g |
| Noise Level @ 30cm | 53 dB |
| Noise Level @ 50cm | 48 dB |
| Operating temperature range | -40℃-100℃ |
| Working Lifespan | 3000 hours |
| Gearbox Characteristic Data | |
| Model | PG56 56 mm Planetary Gearbox |
| Gearbox housing material | Powder Metallurgy (Fe) |
| Gear material | Powder Metallurgy (Fe) / Plastics |
| Gear design | Helical Gear |
| Bearing at output shaft | Ball Bearing |
| Lubricant in gearbox | Graphene oil |
| Axial play | ≤ 0.2mm |
| Radial play | ≤ 0.1mm |
| Backlash at no-load | ≤ 1.5° |
| Gear module | 1 M |
| Gearbox Value | |
| Gear ratio | 716 |
| Number of gear stage | 4 |
| Gearbox length | 83.2 mm |
| Max continuous torque | 400 kgf.cm |
| Instantaneous break torque | 1200 kgf.cm |
| Gearbox efficiency | 72 % |
| Gearbox mass | 1012.3 g |
| Output shaft diameter | 12 mm |
| Pinion hole diameter | φ 5.97 / φ 7.96 |
| Operating temperature range | -30 ... 65 °C |
| Electrical characteristics | |
| Terminal resistance | |
| Terminal inductance | |
| Torque constant | |
| Speed constant | |
| Back-EMF constant | |
| Rotor inductance | |
| Rotor inertia | |
| Mechanical characteristics | |
| Weight | 349 g |
| Noise Level @ 30cm | 53 dB |
| Noise Level @ 50cm | 48 dB |
| Operating temperature range | -40℃-100℃ |
| Working Lifespan | 3000 hours |
| Gearbox Characteristic Data | |
| Model | PG56 56 mm Planetary Gearbox |
| Gearbox housing material | Powder Metallurgy (Fe) |
| Gear material | Powder Metallurgy (Fe) / Plastics |
| Gear design | Helical Gear |
| Bearing at output shaft | Ball Bearing |
| Lubricant in gearbox | Graphene oil |
| Axial play | ≤ 0.2mm |
| Radial play | ≤ 0.1mm |
| Backlash at no-load | ≤ 1.5° |
| Gear module | 1 M |
| Gearbox Value | |
| Gear ratio | 512 |
| Number of gear stage | 4 |
| Gearbox length | 83.2 mm |
| Max continuous torque | 400 kgf.cm |
| Instantaneous break torque | 1200 kgf.cm |
| Gearbox efficiency | 72 % |
| Gearbox mass | 1012.3 g |
| Output shaft diameter | 12 mm |
| Pinion hole diameter | φ 5.97 / φ 7.96 |
| Operating temperature range | -30 ... 65 °C |
| Electrical characteristics | |
| Terminal resistance | |
| Terminal inductance | |
| Torque constant | |
| Speed constant | |
| Back-EMF constant | |
| Rotor inductance | |
| Rotor inertia | |
| Mechanical characteristics | |
| Weight | 349 g |
| Noise Level @ 30cm | 53 dB |
| Noise Level @ 50cm | 48 dB |
| Operating temperature range | -40℃-100℃ |
| Working Lifespan | 3000 hours |
| Gearbox Characteristic Data | |
| Model | PG56 56 mm Planetary Gearbox |
| Gearbox housing material | Powder Metallurgy (Fe) |
| Gear material | Powder Metallurgy (Fe) / Plastics |
| Gear design | Helical Gear |
| Bearing at output shaft | Ball Bearing |
| Lubricant in gearbox | Graphene oil |
| Axial play | ≤ 0.2mm |
| Radial play | ≤ 0.1mm |
| Backlash at no-load | ≤ 1.5° |
| Gear module | 1 M |
| Gearbox Value | |
| Gear ratio | 366 |
| Number of gear stage | 4 |
| Gearbox length | 83.2 mm |
| Max continuous torque | 400 kgf.cm |
| Instantaneous break torque | 1200 kgf.cm |
| Gearbox efficiency | 72 % |
| Gearbox mass | 1012.3 g |
| Output shaft diameter | 12 mm |
| Pinion hole diameter | φ 5.97 / φ 7.96 |
| Operating temperature range | -30 ... 65 °C |
| Electrical characteristics | |
| Terminal resistance | |
| Terminal inductance | |
| Torque constant | |
| Speed constant | |
| Back-EMF constant | |
| Rotor inductance | |
| Rotor inertia | |
| Mechanical characteristics | |
| Weight | 349 g |
| Noise Level @ 30cm | 53 dB |
| Noise Level @ 50cm | 48 dB |
| Operating temperature range | -40℃-100℃ |
| Working Lifespan | 3000 hours |
| Gearbox Characteristic Data | |
| Model | PG56 56 mm Planetary Gearbox |
| Gearbox housing material | Powder Metallurgy (Fe) |
| Gear material | Powder Metallurgy (Fe) / Plastics |
| Gear design | Helical Gear |
| Bearing at output shaft | Ball Bearing |
| Lubricant in gearbox | Graphene oil |
| Axial play | ≤ 0.2mm |
| Radial play | ≤ 0.1mm |
| Backlash at no-load | ≤ 1.5° |
| Gear module | 1 M |
| Gearbox Value | |
| Gear ratio | 262 |
| Number of gear stage | 4 |
| Gearbox length | 83.2 mm |
| Max continuous torque | 400 kgf.cm |
| Instantaneous break torque | 1200 kgf.cm |
| Gearbox efficiency | 72 % |
| Gearbox mass | 1012.3 g |
| Output shaft diameter | 12 mm |
| Pinion hole diameter | φ 5.97 / φ 7.96 |
| Operating temperature range | -30 ... 65 °C |
| Electrical characteristics | |
| Terminal resistance | |
| Terminal inductance | |
| Torque constant | |
| Speed constant | |
| Back-EMF constant | |
| Rotor inductance | |
| Rotor inertia | |
| Mechanical characteristics | |
| Weight | 349 g |
| Noise Level @ 30cm | 53 dB |
| Noise Level @ 50cm | 48 dB |
| Operating temperature range | -40℃-100℃ |
| Working Lifespan | 3000 hours |
| Gearbox Characteristic Data | |
| Model | PG56 56 mm Planetary Gearbox |
| Gearbox housing material | Powder Metallurgy (Fe) |
| Gear material | Powder Metallurgy (Fe) / Plastics |
| Gear design | Helical Gear |
| Bearing at output shaft | Ball Bearing |
| Lubricant in gearbox | Graphene oil |
| Axial play | ≤ 0.2mm |
| Radial play | ≤ 0.1mm |
| Backlash at no-load | ≤ 1.5° |
| Gear module | 1 M |
| Gearbox Value | |
| Gear ratio | 138 |
| Number of gear stage | 3 |
| Gearbox length | 68.9 mm |
| Max continuous torque | 400 kgf.cm |
| Instantaneous break torque | 1200 kgf.cm |
| Gearbox efficiency | 72 % |
| Gearbox mass | 822.1 g |
| Output shaft diameter | 12 mm |
| Pinion hole diameter | φ 5.97 / φ 7.96 |
| Operating temperature range | -30 ... 65 °C |
| Electrical characteristics | |
| Terminal resistance | |
| Terminal inductance | |
| Torque constant | |
| Speed constant | |
| Back-EMF constant | |
| Rotor inductance | |
| Rotor inertia | |
| Mechanical characteristics | |
| Weight | 349 g |
| Noise Level @ 30cm | 53 dB |
| Noise Level @ 50cm | 48 dB |
| Operating temperature range | -40℃-100℃ |
| Working Lifespan | 3000 hours |
| Gearbox Characteristic Data | |
| Model | PG56 56 mm Planetary Gearbox |
| Gearbox housing material | Powder Metallurgy (Fe) |
| Gear material | Powder Metallurgy (Fe) / Plastics |
| Gear design | Helical Gear |
| Bearing at output shaft | Ball Bearing |
| Lubricant in gearbox | Graphene oil |
| Axial play | ≤ 0.2mm |
| Radial play | ≤ 0.1mm |
| Backlash at no-load | ≤ 1.5° |
| Gear module | 1 M |
| Gearbox Value | |
| Gear ratio | 99 |
| Number of gear stage | 3 |
| Gearbox length | 68.9 mm |
| Max continuous torque | 400 kgf.cm |
| Instantaneous break torque | 1200 kgf.cm |
| Gearbox efficiency | 72 % |
| Gearbox mass | 822.1 g |
| Output shaft diameter | 12 mm |
| Pinion hole diameter | φ 5.97 / φ 7.96 |
| Operating temperature range | -30 ... 65 °C |
| Electrical characteristics | |
| Terminal resistance | |
| Terminal inductance | |
| Torque constant | |
| Speed constant | |
| Back-EMF constant | |
| Rotor inductance | |
| Rotor inertia | |
| Mechanical characteristics | |
| Weight | 349 g |
| Noise Level @ 30cm | 53 dB |
| Noise Level @ 50cm | 48 dB |
| Operating temperature range | -40℃-100℃ |
| Working Lifespan | 3000 hours |
| Gearbox Characteristic Data | |
| Model | PG56 56 mm Planetary Gearbox |
| Gearbox housing material | Powder Metallurgy (Fe) |
| Gear material | Powder Metallurgy (Fe) / Plastics |
| Gear design | Helical Gear |
| Bearing at output shaft | Ball Bearing |
| Lubricant in gearbox | Graphene oil |
| Axial play | ≤ 0.2mm |
| Radial play | ≤ 0.1mm |
| Backlash at no-load | ≤ 1.5° |
| Gear module | 1 M |
| Gearbox Value | |
| Gear ratio | 71 |
| Number of gear stage | 3 |
| Gearbox length | 68.9 mm |
| Max continuous torque | 400 kgf.cm |
| Instantaneous break torque | 1200 kgf.cm |
| Gearbox efficiency | 72 % |
| Gearbox mass | 822.1 g |
| Output shaft diameter | 12 mm |
| Pinion hole diameter | φ 5.97 / φ 7.96 |
| Operating temperature range | -30 ... 65 °C |
| Electrical characteristics | |
| Terminal resistance | |
| Terminal inductance | |
| Torque constant | |
| Speed constant | |
| Back-EMF constant | |
| Rotor inductance | |
| Rotor inertia | |
| Mechanical characteristics | |
| Weight | 349 g |
| Noise Level @ 30cm | 53 dB |
| Noise Level @ 50cm | 48 dB |
| Operating temperature range | -40℃-100℃ |
| Working Lifespan | 3000 hours |
| Gearbox Characteristic Data | |
| Model | PG56 56 mm Planetary Gearbox |
| Gearbox housing material | Powder Metallurgy (Fe) |
| Gear material | Powder Metallurgy (Fe) / Plastics |
| Gear design | Helical Gear |
| Bearing at output shaft | Ball Bearing |
| Lubricant in gearbox | Graphene oil |
| Axial play | ≤ 0.2mm |
| Radial play | ≤ 0.1mm |
| Backlash at no-load | ≤ 1.5° |
| Gear module | 1 M |
| Gearbox Value | |
| Gear ratio | 27 |
| Number of gear stage | 2 |
| Gearbox length | 50.4 mm |
| Max continuous torque | 200 kgf.cm |
| Instantaneous break torque | 600 kgf.cm |
| Gearbox efficiency | 81 % |
| Gearbox mass | 630 g |
| Output shaft diameter | 12 mm |
| Pinion hole diameter | φ 5.97 / φ 7.96 |
| Operating temperature range | -30 ... 65 °C |
| Electrical characteristics | |
| Terminal resistance | |
| Terminal inductance | |
| Torque constant | |
| Speed constant | |
| Back-EMF constant | |
| Rotor inductance | |
| Rotor inertia | |
| Mechanical characteristics | |
| Weight | 349 g |
| Noise Level @ 30cm | 53 dB |
| Noise Level @ 50cm | 48 dB |
| Operating temperature range | -40℃-100℃ |
| Working Lifespan | 3000 hours |
| Gearbox Characteristic Data | |
| Model | PG56 56 mm Planetary Gearbox |
| Gearbox housing material | Powder Metallurgy (Fe) |
| Gear material | Powder Metallurgy (Fe) / Plastics |
| Gear design | Helical Gear |
| Bearing at output shaft | Ball Bearing |
| Lubricant in gearbox | Graphene oil |
| Axial play | ≤ 0.2mm |
| Radial play | ≤ 0.1mm |
| Backlash at no-load | ≤ 1.5° |
| Gear module | 1 M |
| Gearbox Value | |
| Gear ratio | 19 |
| Number of gear stage | 2 |
| Gearbox length | 50.4 mm |
| Max continuous torque | 200 kgf.cm |
| Instantaneous break torque | 600 kgf.cm |
| Gearbox efficiency | 81 % |
| Gearbox mass | 630 g |
| Output shaft diameter | 12 mm |
| Pinion hole diameter | φ 5.97 / φ 7.96 |
| Operating temperature range | -30 ... 65 °C |
| Electrical characteristics | |
| Terminal resistance | |
| Terminal inductance | |
| Torque constant | |
| Speed constant | |
| Back-EMF constant | |
| Rotor inductance | |
| Rotor inertia | |
| Mechanical characteristics | |
| Weight | 349 g |
| Noise Level @ 30cm | 53 dB |
| Noise Level @ 50cm | 48 dB |
| Operating temperature range | -40℃-100℃ |
| Working Lifespan | 3000 hours |
| Gearbox Characteristic Data | |
| Model | PG56 56 mm Planetary Gearbox |
| Gearbox housing material | Powder Metallurgy (Fe) |
| Gear material | Powder Metallurgy (Fe) / Plastics |
| Gear design | Helical Gear |
| Bearing at output shaft | Ball Bearing |
| Lubricant in gearbox | Graphene oil |
| Axial play | ≤ 0.2mm |
| Radial play | ≤ 0.1mm |
| Backlash at no-load | ≤ 1.5° |
| Gear module | 1 M |
| Gearbox Value | |
| Gear ratio | 5.1 |
| Number of gear stage | 1 |
| Gearbox length | 37.5 mm |
| Max continuous torque | 100 kgf.cm |
| Instantaneous break torque | 300 kgf.cm |
| Gearbox efficiency | 90 % |
| Gearbox mass | 431.1 g |
| Output shaft diameter | 12 mm |
| Pinion hole diameter | φ 5.97 / φ 7.96 |
| Operating temperature range | -30 ... 65 °C |
| Electrical characteristics | |
| Terminal resistance | |
| Terminal inductance | |
| Torque constant | |
| Speed constant | |
| Back-EMF constant | |
| Rotor inductance | |
| Rotor inertia | |
| Mechanical characteristics | |
| Weight | 349 g |
| Noise Level @ 30cm | 53 dB |
| Noise Level @ 50cm | 48 dB |
| Operating temperature range | -40℃-100℃ |
| Working Lifespan | 3000 hours |
| Gearbox Characteristic Data | |
| Model | PG56 56 mm Planetary Gearbox |
| Gearbox housing material | Powder Metallurgy (Fe) |
| Gear material | Powder Metallurgy (Fe) / Plastics |
| Gear design | Helical Gear |
| Bearing at output shaft | Ball Bearing |
| Lubricant in gearbox | Graphene oil |
| Axial play | ≤ 0.2mm |
| Radial play | ≤ 0.1mm |
| Backlash at no-load | ≤ 1.5° |
| Gear module | 1 M |
| Gearbox Value | |
| Gear ratio | 3.7 |
| Number of gear stage | 1 |
| Gearbox length | 37.5 mm |
| Max continuous torque | 100 kgf.cm |
| Instantaneous break torque | 300 kgf.cm |
| Gearbox efficiency | 90 % |
| Gearbox mass | 431.1 g |
| Output shaft diameter | 12 mm |
| Pinion hole diameter | φ 5.97 / φ 7.96 |
| Operating temperature range | -30 ... 65 °C |
| Electrical characteristics | |
| Terminal resistance | |
| Terminal inductance | |
| Torque constant | |
| Speed constant | |
| Back-EMF constant | |
| Rotor inductance | |
| Rotor inertia | |
| Mechanical characteristics | |
| Weight | 349 g |
| Noise Level @ 30cm | 53 dB |
| Noise Level @ 50cm | 48 dB |
| Operating temperature range | -40℃-100℃ |
| Working Lifespan | 3000 hours |
Technical illustrations
Dimensional Drawing
Characteristic curves
Your Choice
Selected Variant
PG56-1896K
Key Features
| Gear stage: | n : 5 |
| Continuous input torque: | 400 kgf.cm |
| Gear breaking torque: | 1200 kgf.cm |
| Gear ratio: | 1896 |
| Diameter : | 56 mm |
| Length: | 99.2 mm |
Selected Variant
PG56-1356K
Key Features
| Gear stage: | n : 5 |
| Continuous input torque: | 400 kgf.cm |
| Gear breaking torque: | 1200 kgf.cm |
| Gear ratio: | 1356 |
| Diameter : | 56 mm |
| Length: | 99.2 mm |
Selected Variant
PG56-970K
Key Features
| Gear stage: | n : 5 |
| Continuous input torque: | 400 kgf.cm |
| Gear breaking torque: | 1200 kgf.cm |
| Gear ratio: | 970 |
| Diameter : | 56 mm |
| Length: | 99.2 mm |
Selected Variant
PG56-716K
Key Features
| Gear stage: | n : 4 |
| Continuous input torque: | 400 kgf.cm |
| Gear breaking torque: | 1200 kgf.cm |
| Gear ratio: | 716 |
| Diameter : | 56 mm |
| Length: | 83.2 mm |
Selected Variant
PG56-512K
Key Features
| Gear stage: | n : 4 |
| Continuous input torque: | 400 kgf.cm |
| Gear breaking torque: | 1200 kgf.cm |
| Gear ratio: | 512 |
| Diameter : | 56 mm |
| Length: | 83.2 mm |
Selected Variant
PG56-366K
Key Features
| Gear stage: | n : 4 |
| Continuous input torque: | 400 kgf.cm |
| Gear breaking torque: | 1200 kgf.cm |
| Gear ratio: | 366 |
| Diameter : | 56 mm |
| Length: | 83.2 mm |
Selected Variant
PG56-262K
Key Features
| Gear stage: | n : 4 |
| Continuous input torque: | 400 kgf.cm |
| Gear breaking torque: | 1200 kgf.cm |
| Gear ratio: | 262 |
| Diameter : | 56 mm |
| Length: | 83.2 mm |
Selected Variant
PG56-138K
Key Features
| Gear stage: | n : 3 |
| Continuous input torque: | 400 kgf.cm |
| Gear breaking torque: | 1200 kgf.cm |
| Gear ratio: | 138 |
| Diameter : | 56 mm |
| Length: | 68.9 mm |
Selected Variant
PG56-99K
Key Features
| Gear stage: | n : 3 |
| Continuous input torque: | 400 kgf.cm |
| Gear breaking torque: | 1200 kgf.cm |
| Gear ratio: | 99 |
| Diameter : | 56 mm |
| Length: | 68.9 mm |
Selected Variant
PG56-71K
Key Features
| Gear stage: | n : 3 |
| Continuous input torque: | 400 kgf.cm |
| Gear breaking torque: | 1200 kgf.cm |
| Gear ratio: | 71 |
| Diameter : | 56 mm |
| Length: | 68.9 mm |
Selected Variant
PG56-27K
Key Features
| Gear stage: | n : 2 |
| Continuous input torque: | 100 kgf.cm |
| Gear breaking torque: | 300 kgf.cm |
| Gear ratio: | 27 |
| Diameter : | 56 mm |
| Length: | 50.4 mm |
Selected Variant
PG56-19K
Key Features
| Gear stage: | n : 2 |
| Continuous input torque: | 100 kgf.cm |
| Gear breaking torque: | 300 kgf.cm |
| Gear ratio: | 19 |
| Diameter : | 56 mm |
| Length: | 50.4 mm |
Selected Variant
PG56-5.1K
Key Features
| Gear stage: | n : 1 |
| Continuous input torque: | 100 kgf.cm |
| Gear breaking torque: | 300 kgf.cm |
| Gear ratio: | 5.1 |
| Diameter : | 56 mm |
| Length: | 37.5 mm |
Selected Variant
PG56-3.7K
Key Features
| Gear stage: | n : 1 |
| Continuous input torque: | 100 kgf.cm |
| Gear breaking torque: | 300 kgf.cm |
| Gear ratio: | 3.7 |
| Diameter : | 56 mm |
| Length: | 37.5 mm |
