Series MG Series
Price scales
| Quantity | Discount | Unit price |
| 1-9 | 0% off | $9.99 |
| 10-99 | 15% off | $8.49 |
| 100+ | 25% off | $7.49 |
Product description
MG
Specifications
Series MG-718Kn : 530 kgf.cm90 kgf.cm71870 mm70 mm- Series MG-478Kn : 530 kgf.cm90 kgf.cm47870 mm70 mm
- Series MG-331Kn : 530 kgf.cm90 kgf.cm33170 mm70 mm
- Series MG-239Kn : 430 kgf.cm90 kgf.cm23970 mm70 mm
- Series MG-190Kn : 430 kgf.cm90 kgf.cm19070 mm70 mm
- Series MG-170Kn : 430 kgf.cm90 kgf.cm17070 mm70 mm
- Series MG-128Kn : 430 kgf.cm90 kgf.cm12870 mm70 mm
- Series MG-90Kn : 430 kgf.cm90 kgf.cm9070 mm70 mm
- Series MG-55Kn : 310 kgf.cm30 kgf.cm5570 mm70 mm
- Series MG-39Kn : 310 kgf.cm30 kgf.cm3970 mm70 mm
- Series MG-25Kn : 310 kgf.cm30 kgf.cm2570 mm70 mm
- Series MG-17.5Kn : 310 kgf.cm30 kgf.cm17.570 mm70 mm
- Series MG-13Kn : 310 kgf.cm30 kgf.cm1370 mm70 mm
| Gearbox Characteristic Data | |
| Model | MG Squared Spur Gearbox |
| Gearbox housing material | Zinc Alloy （Die casting） |
| Gear material | Powder Metallurgy (Fe) / Plastics / Steel |
| Gear design | Helical Gear / Spur Gear |
| Bearing at output shaft | Sleeve Bearing |
| Lubricant in gearbox | FUMIO |
| Shaft axial load | ≤ 5.0 kgf |
| Radial load | ≤ 3.0 kgf |
| Axial play | ≤ 0.35 mm |
| Radial play | ≤ 0.1 mm |
| Backlash at no-load | ≤ 3° |
| Gear module | 0.4 M / 0.5 M / 0.6 M / 0.8 M |
| Gearbox Value | |
| Gear ratio | 718 |
| Number of gear stage | 5 |
| Max continuous torque | 30 kgf.cm |
| Instantaneous break torque | 90 kgf.cm |
| Gearbox efficiency | 59 % |
| Gearbox mass | |
| Output shaft diameter | 8 mm |
| Pinion hole diameter | φ 3.12 |
| Operating temperature range | -20 ... 65 °C |
| Operating relative humidity | 20% - 85% RH |
| Electrical characteristics | |
| Terminal resistance | |
| Terminal inductance | |
| Torque constant | |
| Speed constant | |
| Back-EMF constant | |
| Rotor inductance | |
| Rotor inertia | |
| Mechanical characteristics | |
| Weight | 103 g |
| Noise Level @ 30cm | 53 dB |
| Noise Level @ 50cm | 48 dB |
| Operating temperature range | -40℃-100℃ |
| Working Lifespan | 3000 hours |
| Gearbox Characteristic Data | |
| Model | MG Squared Spur Gearbox |
| Gearbox housing material | Zinc Alloy （Die casting） |
| Gear material | Powder Metallurgy (Fe) / Plastics / Steel |
| Gear design | Helical Gear / Spur Gear |
| Bearing at output shaft | Sleeve Bearing |
| Lubricant in gearbox | FUMIO |
| Shaft axial load | ≤ 5.0 kgf |
| Radial load | ≤ 3.0 kgf |
| Axial play | ≤ 0.35 mm |
| Radial play | ≤ 0.1 mm |
| Backlash at no-load | ≤ 3° |
| Gear module | 0.4 M / 0.5 M / 0.6 M / 0.8 M |
| Gearbox Value | |
| Gear ratio | 478 |
| Number of gear stage | 5 |
| Max continuous torque | 30 kgf.cm |
| Instantaneous break torque | 90 kgf.cm |
| Gearbox efficiency | 59 % |
| Gearbox mass | |
| Output shaft diameter | 8 mm |
| Pinion hole diameter | φ 3.12 |
| Operating temperature range | -20 ... 65 °C |
| Operating relative humidity | 20% - 85% RH |
| Electrical characteristics | |
| Terminal resistance | |
| Terminal inductance | |
| Torque constant | |
| Speed constant | |
| Back-EMF constant | |
| Rotor inductance | |
| Rotor inertia | |
| Mechanical characteristics | |
| Weight | 103 g |
| Noise Level @ 30cm | 53 dB |
| Noise Level @ 50cm | 48 dB |
| Operating temperature range | -40℃-100℃ |
| Working Lifespan | 3000 hours |
| Gearbox Characteristic Data | |
| Model | MG Squared Spur Gearbox |
| Gearbox housing material | Zinc Alloy （Die casting） |
| Gear material | Powder Metallurgy (Fe) / Plastics / Steel |
| Gear design | Helical Gear / Spur Gear |
| Bearing at output shaft | Sleeve Bearing |
| Lubricant in gearbox | FUMIO |
| Shaft axial load | ≤ 5.0 kgf |
| Radial load | ≤ 3.0 kgf |
| Axial play | ≤ 0.35 mm |
| Radial play | ≤ 0.1 mm |
| Backlash at no-load | ≤ 3° |
| Gear module | 0.4 M / 0.5 M / 0.6 M / 0.8 M |
| Gearbox Value | |
| Gear ratio | 331 |
| Number of gear stage | 5 |
| Max continuous torque | 30 kgf.cm |
| Instantaneous break torque | 90 kgf.cm |
| Gearbox efficiency | 59 % |
| Gearbox mass | |
| Output shaft diameter | 8 mm |
| Pinion hole diameter | φ 3.12 |
| Operating temperature range | -20 ... 65 °C |
| Operating relative humidity | 20% - 85% RH |
| Electrical characteristics | |
| Terminal resistance | |
| Terminal inductance | |
| Torque constant | |
| Speed constant | |
| Back-EMF constant | |
| Rotor inductance | |
| Rotor inertia | |
| Mechanical characteristics | |
| Weight | 103 g |
| Noise Level @ 30cm | 53 dB |
| Noise Level @ 50cm | 48 dB |
| Operating temperature range | -40℃-100℃ |
| Working Lifespan | 3000 hours |
| Gearbox Characteristic Data | |
| Model | MG Squared Spur Gearbox |
| Gearbox housing material | Zinc Alloy （Die casting） |
| Gear material | Powder Metallurgy (Fe) / Plastics / Steel |
| Gear design | Helical Gear / Spur Gear |
| Bearing at output shaft | Sleeve Bearing |
| Lubricant in gearbox | FUMIO |
| Shaft axial load | ≤ 5.0 kgf |
| Radial load | ≤ 3.0 kgf |
| Axial play | ≤ 0.35 mm |
| Radial play | ≤ 0.1 mm |
| Backlash at no-load | ≤ 3° |
| Gear module | 0.4 M / 0.5 M / 0.6 M / 0.8 M |
| Gearbox Value | |
| Gear ratio | 239 |
| Number of gear stage | 4 |
| Max continuous torque | 30 kgf.cm |
| Instantaneous break torque | 90 kgf.cm |
| Gearbox efficiency | 65 % |
| Gearbox mass | |
| Output shaft diameter | 8 mm |
| Pinion hole diameter | φ 3.12 |
| Operating temperature range | -20 ... 65 °C |
| Operating relative humidity | 20% - 85% RH |
| Electrical characteristics | |
| Terminal resistance | |
| Terminal inductance | |
| Torque constant | |
| Speed constant | |
| Back-EMF constant | |
| Rotor inductance | |
| Rotor inertia | |
| Mechanical characteristics | |
| Weight | 103 g |
| Noise Level @ 30cm | 53 dB |
| Noise Level @ 50cm | 48 dB |
| Operating temperature range | -40℃-100℃ |
| Working Lifespan | 3000 hours |
| Gearbox Characteristic Data | |
| Model | MG Squared Spur Gearbox |
| Gearbox housing material | Zinc Alloy （Die casting） |
| Gear material | Powder Metallurgy (Fe) / Plastics / Steel |
| Gear design | Helical Gear / Spur Gear |
| Bearing at output shaft | Sleeve Bearing |
| Lubricant in gearbox | FUMIO |
| Shaft axial load | ≤ 5.0 kgf |
| Radial load | ≤ 3.0 kgf |
| Axial play | ≤ 0.35 mm |
| Radial play | ≤ 0.1 mm |
| Backlash at no-load | ≤ 3° |
| Gear module | 0.4 M / 0.5 M / 0.6 M / 0.8 M |
| Gearbox Value | |
| Gear ratio | 190 |
| Number of gear stage | 4 |
| Max continuous torque | 30 kgf.cm |
| Instantaneous break torque | 90 kgf.cm |
| Gearbox efficiency | 65 % |
| Gearbox mass | |
| Output shaft diameter | 8 mm |
| Pinion hole diameter | φ 3.12 |
| Operating temperature range | -20 ... 65 °C |
| Operating relative humidity | 20% - 85% RH |
| Electrical characteristics | |
| Terminal resistance | |
| Terminal inductance | |
| Torque constant | |
| Speed constant | |
| Back-EMF constant | |
| Rotor inductance | |
| Rotor inertia | |
| Mechanical characteristics | |
| Weight | 103 g |
| Noise Level @ 30cm | 53 dB |
| Noise Level @ 50cm | 48 dB |
| Operating temperature range | -40℃-100℃ |
| Working Lifespan | 3000 hours |
| Gearbox Characteristic Data | |
| Model | MG Squared Spur Gearbox |
| Gearbox housing material | Zinc Alloy （Die casting） |
| Gear material | Powder Metallurgy (Fe) / Plastics / Steel |
| Gear design | Helical Gear / Spur Gear |
| Bearing at output shaft | Sleeve Bearing |
| Lubricant in gearbox | FUMIO |
| Shaft axial load | ≤ 5.0 kgf |
| Radial load | ≤ 3.0 kgf |
| Axial play | ≤ 0.35 mm |
| Radial play | ≤ 0.1 mm |
| Backlash at no-load | ≤ 3° |
| Gear module | 0.4 M / 0.5 M / 0.6 M / 0.8 M |
| Gearbox Value | |
| Gear ratio | 170 |
| Number of gear stage | 4 |
| Max continuous torque | 30 kgf.cm |
| Instantaneous break torque | 90 kgf.cm |
| Gearbox efficiency | 65 % |
| Gearbox mass | |
| Output shaft diameter | 8 mm |
| Pinion hole diameter | φ 3.12 |
| Operating temperature range | -20 ... 65 °C |
| Operating relative humidity | 20% - 85% RH |
| Electrical characteristics | |
| Terminal resistance | |
| Terminal inductance | |
| Torque constant | |
| Speed constant | |
| Back-EMF constant | |
| Rotor inductance | |
| Rotor inertia | |
| Mechanical characteristics | |
| Weight | 103 g |
| Noise Level @ 30cm | 53 dB |
| Noise Level @ 50cm | 48 dB |
| Operating temperature range | -40℃-100℃ |
| Working Lifespan | 3000 hours |
| Gearbox Characteristic Data | |
| Model | MG Squared Spur Gearbox |
| Gearbox housing material | Zinc Alloy （Die casting） |
| Gear material | Powder Metallurgy (Fe) / Plastics / Steel |
| Gear design | Helical Gear / Spur Gear |
| Bearing at output shaft | Sleeve Bearing |
| Lubricant in gearbox | FUMIO |
| Shaft axial load | ≤ 5.0 kgf |
| Radial load | ≤ 3.0 kgf |
| Axial play | ≤ 0.35 mm |
| Radial play | ≤ 0.1 mm |
| Backlash at no-load | ≤ 3° |
| Gear module | 0.4 M / 0.5 M / 0.6 M / 0.8 M |
| Gearbox Value | |
| Gear ratio | 128 |
| Number of gear stage | 4 |
| Max continuous torque | 30 kgf.cm |
| Instantaneous break torque | 90 kgf.cm |
| Gearbox efficiency | 65 % |
| Gearbox mass | |
| Output shaft diameter | 8 mm |
| Pinion hole diameter | φ 3.12 |
| Operating temperature range | -20 ... 65 °C |
| Operating relative humidity | 20% - 85% RH |
| Electrical characteristics | |
| Terminal resistance | |
| Terminal inductance | |
| Torque constant | |
| Speed constant | |
| Back-EMF constant | |
| Rotor inductance | |
| Rotor inertia | |
| Mechanical characteristics | |
| Weight | 103 g |
| Noise Level @ 30cm | 53 dB |
| Noise Level @ 50cm | 48 dB |
| Operating temperature range | -40℃-100℃ |
| Working Lifespan | 3000 hours |
| Gearbox Characteristic Data | |
| Model | MG Squared Spur Gearbox |
| Gearbox housing material | Zinc Alloy （Die casting） |
| Gear material | Powder Metallurgy (Fe) / Plastics / Steel |
| Gear design | Helical Gear / Spur Gear |
| Bearing at output shaft | Sleeve Bearing |
| Lubricant in gearbox | FUMIO |
| Shaft axial load | ≤ 5.0 kgf |
| Radial load | ≤ 3.0 kgf |
| Axial play | ≤ 0.35 mm |
| Radial play | ≤ 0.1 mm |
| Backlash at no-load | ≤ 3° |
| Gear module | 0.4 M / 0.5 M / 0.6 M / 0.8 M |
| Gearbox Value | |
| Gear ratio | 90 |
| Number of gear stage | 4 |
| Max continuous torque | 30 kgf.cm |
| Instantaneous break torque | 90 kgf.cm |
| Gearbox efficiency | 65 % |
| Gearbox mass | |
| Output shaft diameter | 8 mm |
| Pinion hole diameter | φ 3.12 |
| Operating temperature range | -20 ... 65 °C |
| Operating relative humidity | 20% - 85% RH |
| Electrical characteristics | |
| Terminal resistance | |
| Terminal inductance | |
| Torque constant | |
| Speed constant | |
| Back-EMF constant | |
| Rotor inductance | |
| Rotor inertia | |
| Mechanical characteristics | |
| Weight | 103 g |
| Noise Level @ 30cm | 53 dB |
| Noise Level @ 50cm | 48 dB |
| Operating temperature range | -40℃-100℃ |
| Working Lifespan | 3000 hours |
| Gearbox Characteristic Data | |
| Model | MG Squared Spur Gearbox |
| Gearbox housing material | Zinc Alloy （Die casting） |
| Gear material | Powder Metallurgy (Fe) / Plastics / Steel |
| Gear design | Helical Gear / Spur Gear |
| Bearing at output shaft | Sleeve Bearing |
| Lubricant in gearbox | FUMIO |
| Shaft axial load | ≤ 5.0 kgf |
| Radial load | ≤ 3.0 kgf |
| Axial play | ≤ 0.35 mm |
| Radial play | ≤ 0.1 mm |
| Backlash at no-load | ≤ 3° |
| Gear module | 0.4 M / 0.5 M / 0.6 M / 0.8 M |
| Gearbox Value | |
| Gear ratio | 55 |
| Number of gear stage | 3 |
| Max continuous torque | 10 kgf.cm |
| Instantaneous break torque | 30 kgf.cm |
| Gearbox efficiency | 73 % |
| Gearbox mass | |
| Output shaft diameter | 8 mm |
| Pinion hole diameter | φ 2.5 |
| Operating temperature range | -20 ... 65 °C |
| Operating relative humidity | 20% - 85% RH |
| Electrical characteristics | |
| Terminal resistance | |
| Terminal inductance | |
| Torque constant | |
| Speed constant | |
| Back-EMF constant | |
| Rotor inductance | |
| Rotor inertia | |
| Mechanical characteristics | |
| Weight | 103 g |
| Noise Level @ 30cm | 53 dB |
| Noise Level @ 50cm | 48 dB |
| Operating temperature range | -40℃-100℃ |
| Working Lifespan | 3000 hours |
| Gearbox Characteristic Data | |
| Model | MG Squared Spur Gearbox |
| Gearbox housing material | Zinc Alloy （Die casting） |
| Gear material | Powder Metallurgy (Fe) / Plastics / Steel |
| Gear design | Helical Gear / Spur Gear |
| Bearing at output shaft | Sleeve Bearing |
| Lubricant in gearbox | FUMIO |
| Shaft axial load | ≤ 5.0 kgf |
| Radial load | ≤ 3.0 kgf |
| Axial play | ≤ 0.35 mm |
| Radial play | ≤ 0.1 mm |
| Backlash at no-load | ≤ 3° |
| Gear module | 0.4 M / 0.5 M / 0.6 M / 0.8 M |
| Gearbox Value | |
| Gear ratio | 39 |
| Number of gear stage | 3 |
| Max continuous torque | 10 kgf.cm |
| Instantaneous break torque | 30 kgf.cm |
| Gearbox efficiency | 73 % |
| Gearbox mass | |
| Output shaft diameter | 8 mm |
| Pinion hole diameter | φ 2.5 |
| Operating temperature range | -20 ... 65 °C |
| Operating relative humidity | 20% - 85% RH |
| Electrical characteristics | |
| Terminal resistance | |
| Terminal inductance | |
| Torque constant | |
| Speed constant | |
| Back-EMF constant | |
| Rotor inductance | |
| Rotor inertia | |
| Mechanical characteristics | |
| Weight | 103 g |
| Noise Level @ 30cm | 53 dB |
| Noise Level @ 50cm | 48 dB |
| Operating temperature range | -40℃-100℃ |
| Working Lifespan | 3000 hours |
| Gearbox Characteristic Data | |
| Model | MG Squared Spur Gearbox |
| Gearbox housing material | Zinc Alloy （Die casting） |
| Gear material | Powder Metallurgy (Fe) / Plastics / Steel |
| Gear design | Helical Gear / Spur Gear |
| Bearing at output shaft | Sleeve Bearing |
| Lubricant in gearbox | FUMIO |
| Shaft axial load | ≤ 5.0 kgf |
| Radial load | ≤ 3.0 kgf |
| Axial play | ≤ 0.35 mm |
| Radial play | ≤ 0.1 mm |
| Backlash at no-load | ≤ 3° |
| Gear module | 0.4 M / 0.5 M / 0.6 M / 0.8 M |
| Gearbox Value | |
| Gear ratio | 25 |
| Number of gear stage | 3 |
| Max continuous torque | 10 kgf.cm |
| Instantaneous break torque | 30 kgf.cm |
| Gearbox efficiency | 73 % |
| Gearbox mass | 340 g |
| Output shaft diameter | 8 mm |
| Pinion hole diameter | φ 2.5 |
| Operating temperature range | -20 ... 65 °C |
| Operating relative humidity | 20% - 85% RH |
| Electrical characteristics | |
| Terminal resistance | |
| Terminal inductance | |
| Torque constant | |
| Speed constant | |
| Back-EMF constant | |
| Rotor inductance | |
| Rotor inertia | |
| Mechanical characteristics | |
| Weight | 103 g |
| Noise Level @ 30cm | 53 dB |
| Noise Level @ 50cm | 48 dB |
| Operating temperature range | -40℃-100℃ |
| Working Lifespan | 3000 hours |
| Gearbox Characteristic Data | |
| Model | MG Squared Spur Gearbox |
| Gearbox housing material | Zinc Alloy （Die casting） |
| Gear material | Powder Metallurgy (Fe) / Plastics / Steel |
| Gear design | Helical Gear / Spur Gear |
| Bearing at output shaft | Sleeve Bearing |
| Lubricant in gearbox | FUMIO |
| Shaft axial load | ≤ 5.0 kgf |
| Radial load | ≤ 3.0 kgf |
| Axial play | ≤ 0.35 mm |
| Radial play | ≤ 0.1 mm |
| Backlash at no-load | ≤ 3° |
| Gear module | 0.4 M / 0.5 M / 0.6 M / 0.8 M |
| Gearbox Value | |
| Gear ratio | 17.5 |
| Number of gear stage | 3 |
| Max continuous torque | 10 kgf.cm |
| Instantaneous break torque | 30 kgf.cm |
| Gearbox efficiency | 73 % |
| Gearbox mass | 340 g |
| Output shaft diameter | 8 mm |
| Pinion hole diameter | φ 2.5 |
| Operating temperature range | -20 ... 65 °C |
| Operating relative humidity | 20% - 85% RH |
| Electrical characteristics | |
| Terminal resistance | |
| Terminal inductance | |
| Torque constant | |
| Speed constant | |
| Back-EMF constant | |
| Rotor inductance | |
| Rotor inertia | |
| Mechanical characteristics | |
| Weight | 103 g |
| Noise Level @ 30cm | 53 dB |
| Noise Level @ 50cm | 48 dB |
| Operating temperature range | -40℃-100℃ |
| Working Lifespan | 3000 hours |
| Gearbox Characteristic Data | |
| Model | MG Squared Spur Gearbox |
| Gearbox housing material | Zinc Alloy （Die casting） |
| Gear material | Powder Metallurgy (Fe) / Plastics / Steel |
| Gear design | Helical Gear / Spur Gear |
| Bearing at output shaft | Sleeve Bearing |
| Lubricant in gearbox | FUMIO |
| Shaft axial load | ≤ 5.0 kgf |
| Radial load | ≤ 3.0 kgf |
| Axial play | ≤ 0.35 mm |
| Radial play | ≤ 0.1 mm |
| Backlash at no-load | ≤ 3° |
| Gear module | 0.4 M / 0.5 M / 0.6 M / 0.8 M |
| Gearbox Value | |
| Gear ratio | 13 |
| Number of gear stage | 3 |
| Max continuous torque | 10 kgf.cm |
| Instantaneous break torque | 30 kgf.cm |
| Gearbox efficiency | 73 % |
| Gearbox mass | 340 g |
| Output shaft diameter | 8 mm |
| Pinion hole diameter | φ 2.5 |
| Operating temperature range | -20 ... 65 °C |
| Operating relative humidity | 20% - 85% RH |
| Electrical characteristics | |
| Terminal resistance | |
| Terminal inductance | |
| Torque constant | |
| Speed constant | |
| Back-EMF constant | |
| Rotor inductance | |
| Rotor inertia | |
| Mechanical characteristics | |
| Weight | 103 g |
| Noise Level @ 30cm | 53 dB |
| Noise Level @ 50cm | 48 dB |
| Operating temperature range | -40℃-100℃ |
| Working Lifespan | 3000 hours |
Technical illustrations
Dimensional Drawing
Characteristic curves
Your Choice
Selected Variant
MG-718K
Key Features
| Gear stage: | n : 5 |
| Continuous input torque: | 30 kgf.cm |
| Gear breaking torque: | 90 kgf.cm |
| Gear ratio: | 718 |
| Diameter : | 70 mm |
| Length: | 70 mm |
Selected Variant
MG-478K
Key Features
| Gear stage: | n : 5 |
| Continuous input torque: | 30 kgf.cm |
| Gear breaking torque: | 90 kgf.cm |
| Gear ratio: | 478 |
| Diameter : | 70 mm |
| Length: | 70 mm |
Selected Variant
MG-331K
Key Features
| Gear stage: | n : 5 |
| Continuous input torque: | 30 kgf.cm |
| Gear breaking torque: | 90 kgf.cm |
| Gear ratio: | 331 |
| Diameter : | 70 mm |
| Length: | 70 mm |
Selected Variant
MG-239K
Key Features
| Gear stage: | n : 4 |
| Continuous input torque: | 30 kgf.cm |
| Gear breaking torque: | 90 kgf.cm |
| Gear ratio: | 239 |
| Diameter : | 70 mm |
| Length: | 70 mm |
Selected Variant
MG-190K
Key Features
| Gear stage: | n : 4 |
| Continuous input torque: | 30 kgf.cm |
| Gear breaking torque: | 90 kgf.cm |
| Gear ratio: | 190 |
| Diameter : | 70 mm |
| Length: | 70 mm |
Selected Variant
MG-170K
Key Features
| Gear stage: | n : 4 |
| Continuous input torque: | 30 kgf.cm |
| Gear breaking torque: | 90 kgf.cm |
| Gear ratio: | 170 |
| Diameter : | 70 mm |
| Length: | 70 mm |
Selected Variant
MG-128K
Key Features
| Gear stage: | n : 4 |
| Continuous input torque: | 30 kgf.cm |
| Gear breaking torque: | 90 kgf.cm |
| Gear ratio: | 128 |
| Diameter : | 70 mm |
| Length: | 70 mm |
Selected Variant
MG-90K
Key Features
| Gear stage: | n : 4 |
| Continuous input torque: | 30 kgf.cm |
| Gear breaking torque: | 90 kgf.cm |
| Gear ratio: | 90 |
| Diameter : | 70 mm |
| Length: | 70 mm |
Selected Variant
MG-55K
Key Features
| Gear stage: | n : 3 |
| Continuous input torque: | 10 kgf.cm |
| Gear breaking torque: | 30 kgf.cm |
| Gear ratio: | 55 |
| Diameter : | 70 mm |
| Length: | 70 mm |
Selected Variant
MG-39K
Key Features
| Gear stage: | n : 3 |
| Continuous input torque: | 10 kgf.cm |
| Gear breaking torque: | 30 kgf.cm |
| Gear ratio: | 39 |
| Diameter : | 70 mm |
| Length: | 70 mm |
Selected Variant
MG-25K
Key Features
| Gear stage: | n : 3 |
| Continuous input torque: | 10 kgf.cm |
| Gear breaking torque: | 30 kgf.cm |
| Gear ratio: | 25 |
| Diameter : | 70 mm |
| Length: | 70 mm |
Selected Variant
MG-17.5K
Key Features
| Gear stage: | n : 3 |
| Continuous input torque: | 10 kgf.cm |
| Gear breaking torque: | 30 kgf.cm |
| Gear ratio: | 17.5 |
| Diameter : | 70 mm |
| Length: | 70 mm |
Selected Variant
MG-13K
Key Features
| Gear stage: | n : 3 |
| Continuous input torque: | 10 kgf.cm |
| Gear breaking torque: | 30 kgf.cm |
| Gear ratio: | 13 |
| Diameter : | 70 mm |
| Length: | 70 mm |
